PRAMAC P 4500i Inverter

Parametre

Single-phase maximum power (LTP): n.a.
Single-phase maximum power (LTP).: n.a.
Single-phase prime power (PRP): n.a.
Single-phase prime power (PRP).: n.a.
Single-phase continuous power (COP): n.a.
Single-phase continuous power (COP): n.a.
Rated maximum power (LTP): 4,3 kVA
Rated maximum power (LTP): 4,3 kW
Rated prime power (PRP): 4,3 kVA
Rated prime power (PRP): 4,3 kW
Rated continuous power (COP): 3,8 kVA
Rated continuous power (COP): 3,8 kW
Rated current at COP: 16,5 A
Phases: 1
Voltage: 230 V
Rated power factor: 1,0 PF
Frequency: 50 Hz
Battery charger voltage: 12 V
Battery charger current: 8,3 A
Panel location: Canopied
Frame type: Canopied
Compliancy certification: CE
Engine specifications
Engine manufacturer: Robin
Model: EX27
Stroke: 4
Fuel: Gasoline
Number of cylinders and disposition: 1, inclination angle
Displacement: 265 cm³
Air intake: Natural
Starting system: Electric - Recoil
Nominal operating speed: 3600 rpm
Speed governor: Mechanical
Continuous power COP: 5,1 kW
Prime power PRP: 5,6 kW
Standby power LTP: 6,3 kW
Lube oil capacity: 1,1 l
Fuel consumption at 75% load: 1,66 l/h
Electric circuit voltage: 12 V
Alternator specifications
Alternator manufacturer: Robin
Model: n.a.
Poles: 16
Revolution speed: n.a.
Voltage: 230 V
Frequency: 50 Hz
Efficiency at 75% load: 70 %
Maximum admitted overload: 10% for 1 hour every 6 hours of running time S2
Voltage regulation system: Inverter
Protection grade: IP 23
Additional information
Skid mounting: No
Fuel tank location: On canopy
Fuel tank capacity: 12,8 l
Automatic supplementary tank VV.FF.: No
Running time at 75% COP: 7,73 h
Measured acoustic power (LWA) at 4 mt: 91,7 dBA
Noise level at 7 m: 62 dBA
Guaranteed noise level (LWA): 93 dBA
Operating conditions: -15 ~ +40 °C
Dimensional data
Length: 580 mm
Width: 527 mm
Height: 618 mm
Dry weight: 74 kg
